Description
SafeWaze 018-5037 7′ Web 20″ Wear Pad, Dual Leg Tie Back Retractable with 9013 BWB
Item#: 018-5037
The SafeWaze 018-5037 20″ tie back SRL comes with our 9013 behind the web bracket, and 3/4″ Steel Tie Back Snaphook. It has all the same lightweight and durable features offered in our standard 7′ series.
Our 20″ wear pad offering is designed for working environments where longer tie back webbing could possibly create a hazard in relation to moving equipment, chemical contact, or other potential hazards.
The housing also makes for easy viewing and inspection of the webbing, reserve line, and pawl assembly. This unit comes with our 1014 behind the web bracket.
FEATURES
- 7′ length
- Steel tie-back snap hooks
- High strength clear plastic housing
- 20″ of wear pad protected webbing
- 17″ max. circumference tie-back connection
- Steel tie back snap hooks with 5,000 lb. gate
- .77 in (19.5 mm) Ultrahigh molecular weight webbing
- 8.5’ non tie back when used in overhead applications
- Class A up to 24 in (60.96 cm) if used above Dorsal D-ring
- Class B up to 54 in (137.16 cm) if used up to a maximum of 2 ft
below Dorsal D-ring
- User Capacity: ANSI 130-310 lbs. and OSHA 420 lbs. (max)
- 9013 behind the web bracket included
- Available in Dual and Single leg configuration with a variety of attachment options
below Dorsal D-ring
SPECIFICATIONS
| Materials | High-strength clear plastic housing, .77 in (19.5 mm) Ultrahigh Molecular Weight Webbing, Steel Tie Back snap hooks |
| Weight | 5.9 lbs. |
| Weight Capacity/Max Working Load | ANSI 130-310 lbs (58.97-140.61 kg) OSHA up to 420 lbs (190.51 kg) |
| Maximum Arrest Distance | Class A up to 24 in (60.96 cm) if used above Dorsal D-ring Class B up to 54 in (137.16 cm) if used up to a maximum of 2 ft below Dorsal D-ring |
| Length | 7 ft (2.13 m) |
| Hook Rating | 5,000 lbs (2267.96 kg) Tensile Strength 3,600 lbs (1632 kg) Gate Rated |
| Applicable Standards | Meets OSHA 1926.502 – ANSI Z359.14 – ANSI A10.32 |
